GHSL1742/1842/ FULL RISE SCISSOR LIFT

◆Super low profile and perfect for ground mounted;

◆Suitable for any positioning turn table;

◆Equipped with safety lock, makes the run way more stable ,and more safety operating;

◆Equipped with second lifting jack,which equipped with telescopic sliding beam and bracket.

·	Technical Specification

Rating capacity	3500/4000kg
Runway length	4200/4500mm
Runway Width	635/635mm
Max. Lifting height	1700/1700mm
Min. height	190/190mm
Lifting time	60s
Ack capacity	2500kg
Central jack raised height	450mm
Motor power	2.2kw
Power supply	380V/415V 3phase
Air supply	6~8Kg/cm2
Packing size	4600/4900650700
Weight	2167/2277kg
9 units can be loaded into one 20”container

Details

Packing size and line drawings
